Material

Wavelength λp(nm)

Light Current I_c(on)(mA)

@V_CE=5V Ee=1mW/cm²

Saturation Voltage V_CE(sat)( V)

@I_C =0.1mA

Ee=1mW/cm²

Breakdown Voltage V_BR(CEO)(V)

@I_C=0.1mA Ee=0mW/cm²

Dark Current

I_D(nA) @V_CE=10V Ee=0mW/cm²

Typ.

Max.

Min.

Max.

HPT-0603C-P2-TRZ.pdf

940(400-1100)

10

0.50

30

100

HPT-0603D-PB-TRZ.pdf

940(820-1100)

Black

8

0.50

30

100

HPT-0603D-P2-TRZ.pdf

940(820-1100)

10

0.50

30

100
